ACCOMODATION                                           10 GUESTS + 7 CREW

CLASSIFICATION                                            Rina Pleasure Yachts (Private or MCA)

LENGTH OVER ALL                                        30-38 meters

LENGTH WATERLINE                                    28-33 meters

BEAM                                                                 7-8 meters

DRAFT                                                                1.98 meters

DISPLACEMENT (Light Ship)                       150 Tonnes

DISPLACEMENT (Fully loaded)                   190 Tonnes

GROSS TONNAGE                                           275 GT (Approx.)

SPEED                                                                22-24 Knots  (Depending the Engine Package

PROPULSION

MAIN ENGINES:  2 x CAT C32 2000-2200HP (Optional MTU 16V2000 M96)

GEARBOX : ZF3050 SERIES 2,98:1

ENGINE CONTROL: GLENDINING ( 1 main + 2 remote station)

GENERATORS: 2X  CAT C4.4, 65 KW

SHAFT PROPELLER: CJR (UK)  4,5” MARINEMET 25 Shaft  / 5 Blades Class S Propellers

ELECTRIC SYSTEM: 120/ 208 / 220 VAC 3P 50/60Hz  Main Service

                               24VDC Service and Engine Start System

                               ASEA 65 kVA Shore Power Converter

                               2x Glendinning CM9 Cable Master

TANK CAPACITY  Varies depending the size. Tankage capacity below is for the 38m

Diesel Oil: 20800 Lt / 5.500 Gallons

Fresh Water: 4.000 Lt / 1.000 Gallons

Black Water: 2.000 Lt/ 500 Gallons

GreyWater : 2.700 Lt / 700 Gallons

BUILD / CONSTRUCTION

HULL / SUPERSTRUCTURE : CARBON RAINFORCED E-GLASS - EPOXY COMPOSITE SANDWICH

OPEN DECK: HANDLAID BURMESE / MYANMAR TEAK OR NON SKID PAINT

PAINT SYSTEM: AWLGRIP

Bow thruster/ Stern Thruster: Sleipner

Stabilizers: Sleipner at Rest Stabilizer with Power Pack
